STEDI ST2K Curved Light Bar - 40.5"

ADVANTAGES OF A LATERAL SPOT BEAM

• Excellent well rounded mid to long-range illumination
• Significantly minimizes adverse reflection from road signs
• Eliminates light wasted on illuminating tree tops (won’t disturb sleeping koalas)
• An excellent alternative to HID, without the associated downsides
• The beam is 90m wide at approx 250m

KEY FEATURES

• LED Parking / Position Light Function
• Breather allows pressure equalization when rapid heat up and cool down cycles occur.
• Anodized Polyester Powder Coat
• Weatherproof Deutsch® DT2 Connector.
• Includes adjustable side brackets
• Includes our Easy-Fit Plug & Play High Beam Wiring Harness with HB3 & H4 adapter (compatible with both negative and positive switched vehicles).
• Protected against reverse polarity
• Shockproof, IP68 waterproof, UV Shielded
• Protected against RFI / EMC Interference
• Voltage & current surge protection
• Pulse Width Modulation Thermal Management

TECH SPECS

• Main Beam LED Count: 16 × 15W
• Voltage: 12V & 24V
• DRL Voltage: 12–24V Compatible
• Lens Material: Optical Grade Hard-Coated Lexan
• Lumens: 16,000 lm
• Housing Material: 6063 Aluminium Extrusion
• Current Draw: 16.1A @ 13.2V
• Lifespan: 50,000 Hours
• Beam Pattern: Driving Beam (Spot)
• Ingress Protection: IP68
• Operating Temperature: -40°C to +150°C
• Weight: 4.795 kg
• Certifications: E-Mark R10, CE ✓
