STEDI ST2K Curved Light Bar - 40.5"

ADVANTAGES OF A LATERAL DRIVING BEAM

• Excellent well rounded mid to long range illumination
• Significantly minimises adverse reflection from road signs
• Eliminates light wasted on illuminating tree tops (won’t disturb sleeping koalas)
• Excellent alternative to HID, without the associated downsides
• 70m wide beam at around 150m.

KEY FEATURES

• LED Parking / Position Light Function
• Breather allows pressure equalization when rapid heat up and cool down cycles occur.
• Anodized Polyester Powder Coat
• Weatherproof Deutsch® DT2 Connector.
• Includes adjustable sliding mounts and side brackets
• Includes our Easy-Fit Plug & Play High Beam Wiring Harness with HB3 & H4 adapter (Compatible with both negative and positive switched vehicles.
• Protected against reverse polarity
• Shock proof, IP68 waterproof, UV Shielded
• Protected against RFI / EMC Interference
• Voltage & current surge protection
• Pulse Width Modulation Thermal Management

WHAT’S IN THE BOX

• 1 x 40.5" ST2K-16L LED Light Bar
• 2 x Steel Side Brackets
• Easy-Fit High Beam Wiring Kit | HB3 & H4 piggy-back included.
• Wiring Instructions
• Comprehensive 304 Stainless Steel fasteners

SPECIFICATIONS:

• Main Beam LED Count: 16 x 15W

• Voltage: 12V & 24V

• Lens Material: Optical Grade, Hard Coated Lexan

• Lumens: 16,000

• Housing Material: 6063 Extrusion

• Amperes: 16.1A @ 13.2V

• Lifespan: 50,000 Hours

• Spot Beam: Driving Beam

• Ingress Protection: IP68

• Operating Temp: -40˚C to +150˚C

• Weight: 4.795 kg
